Quarry Range

Quarry Range

The Quarry Range of finishes has been designed to capture popular stone types including natural stone and GRC and gives a whole new perspective on the use of stone. A range of super-durable high-grade architectural coatings with a sand-blasted appearance.

The Quarry Range offers a deep-matt, realistic stone-effect finish for architectural metalwork as a great alternative to real stone.

Suitable for Architectural Metalwork

  • Aluminium
  • Mild Steel
  • Stainless Steel
  • Cast Metals
  • Galvanised and Zinc Sprayed Substrates
  • Qualizinc Arc Metal Spray

Properties and Finish Characteristics

  • Excellent textured natural stone and glass reinforced concrete (GRC) effects
  • Very low matt sheen levels giving the appearance of solid, natural stone
  • Excellent for architectural applications, both internal and external
  • Superior resistance to wear and tear
  • Compatible with a variety of anti-corrosion treatments
  • Meets Qualicoat and Qualisteelcoat International Standards
  • Used in conjunction with Bradleys Bondakote Primer system creates excellent adhesion and greater longevity
  • Environments – Interior and Exterior: C1, C2, C3, C4 and C5
  • Gloss Level – Deep matt (5 – 7 GU)
  • Warranty – up to 40 years dependent upon environment

Advantages over Real Stone

  • No weight issues, reduced structural loading
  • No dust and suppression needed
  • No heavy logistical issues
  • Ease of installation
  • Cost effective
  • Has applications where stone can’t be used

Durability and Weather Resistance Performance

  • Accelerated Weathering – Class 2 ISO 16474-2 (1000 hrs) ≥90% Gloss retention
  • Neutral Salt Spray (Vern to advise following Pawel’s departure)
  • Acetic Salt Spray Resistance – ISO 9227 <16 mm2 corrosion/10cm, 1000 hours (aluminium)
  • Adhesion – Achieved the ultimate Class 0 in accordance with ISO 2409
  • Chemical Resistance – Resistant to solvents (Xylene rub test)
  • Florida Exposure – Gloss retention compliant with Qualicoat Class 2 requirements
  • Flexibility – SO 1519 (cylindrical Mandrel) Pass Qualicoat class 2 requirements
  • Excellent colour stability at elevated temperatures
  • Permeability Resistance – No sign of detachment or blistering as per Qualicoat specification
  • Mortar Resistance – As per Standard EN 12206, no effect after 24 hours
  • Impact Resistance – No sign of detachment following the tape pull adhesion test

Fire Rating

  • All Quarry finishes are available in Fire Rated versions (Rated to A2-s1,d0) on prior request

Environment

  • Quarry Range offers several environmental benefits within the parameters of ISO 14001 environmental management system:
  • Low VOC Emissions: Quarry finishes emit minimal volatile organic compounds (VOCs) into the air
  • Efficient Application: When applying Quarry powder, about 90% of what’s sprayed adheres to the metal surface. The remaining powder can be collected, filtered and reused
  • Elimination of Hazardous Substances: Quarry finishes do not require hazardous air pollutants (HAPs)
  • Enhanced Durability: Quarry-finished surfaces are highly durable, reducing the need for frequent repair and requiring fewer resources used over time
  • TGIC Free: Eliminating the risk of TGIC related adverse health effects
  • Lightweight Materials: Quarry powders add no significant weight to the substrate contributing to energy-efficient designs
  • Promotes Sustainability: Vantage Texture-finished products are more sustainable due to their durability, reducing the demand for new raw materials

Repair & Maintenance

  • Expected Life to first maintenance of 50 years
  • Simple and easy to clean with pH neutral water and soft cloth or sponge
  • Damage repair systems available for onsite application
Bearl Cream BR 11406
Textured Concrete BR 11403
Beige Limestone BR 10105
