Ano-Dura Range

Vantage Ano-Dura Range

The Ano-Dura Range of High-Grade Architectural Powders is a super durable range of polyester powder finishes designed to protect the substrate and to retain a decorative, durable, long-life anodize-effect finish.

The Ano-Dura Range of powders is designed for areas where attention to aesthetics and quality is important. Available in a unique selection of superior quality low sheen shades to compliment current architectural design trends.

Suitable for Architectural Metalwork

  • Aluminium
  • Mild Steel
  • Stainless Steel
  • Galvanised and Zinc Coated Substrates
  • Qualizinc Arc Metal Spray

Properties and Finish Characteristics

  • Available in the following colours: Black, Bronze, Gold, Grey and other colours on request
  • Metallic low-sheen finishes
  • Appealing anodize-effect finish with a unique look, and can disguise imperfections on the underlying surface
  • Superior resistance to wear and tear
  • Compatible with a variety of anti-corrosion treatments
  • Meets Qualicoat and Qualisteelcoat International Standards
  • Used in conjunction with Bradleys Bondakote Primer system creates excellent adhesion and greater longevity
  • Environments – Interior and Exterior: C1, C2, C3, C4 and C5
  • Gloss category / Gloss range / Acceptable variation 1 (matt) 0 – 30 +/- 5 units 2 (satin) 31 – 70 +/- 7 units 3 (gloss) 71 – 100 +/- 10 units
  • Warranty – Up to 40 years dependent upon environment

Advantages over Anodizing

  • Can be applied to a variety of metal substrates and different shapes and sizes, whereas anodizing can only be applied to certain types of aluminium within tank size constraints
  • Anodized coatings are difficult to repair once damaged, unlike Ano-Dura which can easily be touched up or recoated
  • Ano-Dura does not require costly and time-consuming meticulous cleaning and preparation of the metal surface compared to anodizing
  • Ano-Dura will give you consistency of colour from panel to panel

Durability and Weather Resistance Performance

  • Accelerated Weathering – Class 2 ISO 16474-2 (1000 hrs) ≥90% Gloss retention
  • Acetic Salt Spray Resistance – ISO 9227 <16 mm2 corrosion/10cm, 1000 hours (aluminium)
  • Adhesion – Achieved the ultimate Class 0 in accordance with ISO 2409
  • Chemical Resistance – Resistant to solvents (Xylene rub test)
  • Florida Exposure – Gloss retention compliant with Qualicoat Class 2 requirements
  • Flexibility – SO 1519 (cylindrical Mandrel) Pass Qualicoat class 2 requirements
  • Excellent colour stability at elevated temperatures
  • Permeability Resistance – No sign of detachment or blistering as per Qualicoat specification
  • Mortar Resistance – As per Standard EN 12206, no effect after 24 hours
  • Impact Resistance – No sign of detachment following the tape pull adhesion test

Fire Rating

  • A number of Ano-Dura finishes are available in Fire Rated versions (Rated to A2-s1,d0) on prior request

Environment

  • Ano-Dura Range offers several environmental benefits within the parameters of ISO 14001 Environmental Management System:
  • Low VOC Emissions: Ano-Dura finishes emit minimal volatile organic compounds (VOCs) into the air
  • Efficient Application: When applying Ano-Dura powder, about 90% of what’s sprayed adheres to the metal surface. The remaining powder can be collected, filtered and reused
  • Energy Reduction: Unlike the anodizing process, Ano-Dura is much less energy-intensive as it does not require electrolysis
  • Water Usage: Unlike anodizing, Ano-Dura requires significantly less water in the production process
  • Elimination of Hazardous Substances: Ano-Dura finishes do not require hazardous air pollutants (HAPs)
  • Enhanced Durability: Ano-Dura-finished surfaces are highly durable, reducing the need for frequent repair and fewer resources required over time
  • TGIC Free: Eliminating the risk of TGIC related adverse health effects
  • Lightweight Materials: Ano-Dura powders add no significant weight to the substrate contributing to energy-efficient designs
  • Promotes Sustainability: Vantage Texture-finished products are more sustainable due to their durability, reducing the demand for new raw materials

Repair & Maintenance

  • Expected Life to First Maintenance of 50 years
  • Simple and easy to clean with pH neutral water and soft cloth or sponge
  • Damage repair systems available for onsite application
